TECHNICAL DATA
Active power measurement accuracy 0.3%, 0.5%
Energy measurement accuracy 0.3%, 0.5%
Power supply AC 110-264V 50/60Hz
Warming-up time < 5 min
Power consumption ≤5VA
Voltage measurement
Range 0-264V
Accuracy 0.30%
Current measurement
Range 10mA-40A or 10mA-120A
Accuracy 0.3%
Phase measurement
Range 0°-359.9°
Resolution 0.1°
Accuracy 0.5°
Frequency measurement
Range 45-65 Hz
Resolution 0.01Hz
Accuracy 0.05Hz
Power factor measurement
Range 0.4000 ~ +1.0000
Resolution 0.001
Accuracy 0.01
Electric energy pulse output
Pulse constant 900
Energy pulseinput
Input range of pulse constant 1-25000
Pulse input level 5V
Mechanical parameters
Dimensions (W×D×H) (mm) 185×67×30
Weight (kg) 1 (mains)
2 (appendix and bag)
Environmental conditions
Working temperature -10°C to 50°C
Working humidity 5%- 85%RHD
Storage temperature -25°C to 70°C
Storage humidity 5% -95%RHD
